Arctic Snow

Arctic Heavy Duty V Trip Edge Poly Blade V108P

  • Arctic Heavy Duty V Trip Edge Poly Blade V108P
  • Arctic Heavy Duty V Trip Edge Poly Blade V108P
  • Arctic Heavy Duty V Trip Edge Poly Blade V108P
  • Arctic Heavy Duty V Trip Edge Poly Blade V108P
  • Arctic Heavy Duty V Trip Edge Poly Blade V108P
  • Arctic Heavy Duty V Trip Edge Poly Blade V108P
 Value a Trade  Get Financed
Overview
Overview

Each horizontally reinforced, steel-backed poly section, comes with a double-acting 1 1/2" X 9" ram. The Arctic V Plow full-grip joystick puts unprecedented control in the palm of your hand. Winter can visit, but it does so on your terms. Built for full-size vehicles and larger.

Specifications
Model
Heavy Duty V Trip Edge Poly Blade
Category Name
Snow Equipment
Year
2025
Sale Type
New
Manufacturer
Arctic
Quantity
1
Manufacturer Qty
0
Blade Skin
3/8" Poly
Blade Height
29"
Blade Length
108"
Cutting Edge
1/2" x 6" Steel
Lift Cylinder
2" x 6"
Mounting Type
Quik*Link™ IV - Detachable
Reinforced Ribs
6
Angling Cylinder
1 1/2" x 9"
Approximate Weight
866 lbs
Compressible Springs
4
Plowing Width At Full Blade Angle
94"
features

6 Laser-Cut Steel Reinforcing RibsArctic Heavy Duty V Trip Edge Poly Blade V108P

Back our friction-less poly moldboard

Hot-Dipped Galvanized Steel FrameArctic Heavy Duty V Trip Edge Poly Blade V108P

Provides added resistance to abrasion,  water and rust, making our plows virtually maintenance free.

4 Adjustable Compression SpringsArctic Heavy Duty V Trip Edge Poly Blade V108P

To compensate for uneven plowing grounds

1/2" x 6" High Carbon Steel Cutting EdgeArctic Heavy Duty V Trip Edge Poly Blade V108P

With top hole bolt pattern

6” Curved DeflectorArctic Heavy Duty V Trip Edge Poly Blade V108P

Rolls the snow nicely, keeps it down on the blade and away from the vehicle's windshield.

Quik*Link™ IV AttachmentArctic Heavy Duty V Trip Edge Poly Blade V108P

Easily locks the blade, power angling and lift frame assembly to mounting kit assembly on vehicle using spring loaded handle.

3/8” Polyethylene MoldboardArctic Heavy Duty V Trip Edge Poly Blade V108P

Throws snow further and faster resulting in less resistance and vehicle wear, and  improved fuel economy.

1 3/16" x 23 1/2" Greaseable KingpinArctic Heavy Duty V Trip Edge Poly Blade V108P

With a Reinforced pin housing comprised of seven 1/2" x 5/8" wall bushings, provides tremendous strength

Double lift chainsArctic Heavy Duty V Trip Edge Poly Blade V108P

For Extra lift, strength and safety

Laser Cut HolesArctic Heavy Duty V Trip Edge Poly Blade V108P

For optional bolt on Wing kits



literature

Name

Link
Brochure Download
