Arctic Snow

Arctic Heavy Duty Steel Blade 102S

Overview
Overview

For decades, the Arctic Heavy Duty Steel has been the reason Canadians have found a parking spot. This go-to plow for commercial applications is constructed of 10 gauge hot rolled steel and is reinforced with seven integrated vertical ribs for tremendous structural strength. The snow roll blade design not only reduces wear and increases fuel efficiency - it also prevents over-the-top snow loss without a snow deflector. Built for full-size vehicles and larger.

Specifications
Model
Heavy Duty Steel Blade
Category Name
Snow Equipment
Year
2025
Sale Type
New
Manufacturer
Arctic
Quantity
1
Manufacturer Qty
0
Blade Skin
10 Ga Steel
Blade Height
27"
Blade Length
102"
Cutting Edge
1/2" x 6" Steel
Trip Springs
4
Lift Cylinder
1 1/2" x 6"
Mounting Type
Quik*Linkā„¢ IV - Detachable
Reinforced Ribs
7
Angling Cylinder
1 1/2" x 10"
Approximate Weight
708 lbs
Plowing Width At Full Blade Angle
88"
features

7 Laser Cut Steel Reinforcing RibsArctic Heavy Duty Steel Blade 102S

For enhanced structural strength

6” Curved DeflectorArctic Heavy Duty Steel Blade 102S

Rolls the snow nicely, keeps it down on the blade and away from the vehicle's windshield.

Quik*Link™ IV AttachmentArctic Heavy Duty Steel Blade 102S

Easily locks the blade, power angling and lift frame assembly to mounting kit assembly on vehicle using spring loaded handle.

Hot-Dipped Galvanized Steel FrameArctic Heavy Duty Steel Blade 102S

Provides added resistance to abrasion,  water and rust, making our plows virtually maintenance free.

Arctic Heavy Duty Steel Blade 102SDish-Shaped Skid Shoes

Improve surface clearance while plowing forward.

Arctic Heavy Duty Steel Blade 102SFully Reversible Hardened, High Carbon Steel Cutting Edge

Lowers blade profile by exposing only 2" of blade at a time, and can be easily flipped when worn to start with a new edge

Arctic Heavy Duty Steel Blade 102STension Springs

Keep the blade upright and offer ample room for addition of a shock absorber kit, if desired

Three 3/4 Pins
Arctic Heavy Duty Steel Blade 102S

Secure the Blade to the Quadrant and A frame assembly, eliminating pin seizure and easing pin replacement
